Baker Performs Multi Heat Exchanger Changeout

Back in early 2021, R. Baker & Son took part in a food manufacturing construction project in which we performed rigging and assembly of six large, high-pressure steam ovens over a ten-week period. Each of the ovens had arrived in multiple pieces and were installed using gantries, pneumatic chain blocks, and large forklifts. Our crew worked in coordination with the oven manufacturer, the project was completed safely and on time, and the ovens were placed into operation.

Many months later, we received a call from the facility owner requesting our assistance. The ovens hadn’t been performing up to par due to a problem with heat exchangers, so the heat exchangers – two in each oven – would require removal and replacement.

Because the plant was in operation around the clock, the replacements would have to be done one at a time. Individual ovens were locked and tagged out as work progressed and isolated with barriers to prevent access by plant personnel. Maneuvering space near and between the ovens was somewhat tight, so the Baker crew used two small forklifts to perform the job. First, the ovens’ side covers were removed to provide access to the heat exchangers. We unbolted the 3-inch steam flanges secured to the units and removed them from their internal supports using electric chain blocks and the forklifts. The new heat exchangers were moved into place and remounted onto their supports, followed by reconnection of the steam flanges. Once each heat exchangers had been successfully pressure-tested, we reinstalled the covers and turned the ovens over to the facility for testing and commissioning.

This one-by-one process continued, working around the plant’s manufacturing schedule and oven availability, and the project was successfully completed within a four-week period.
